Skid Steer Loader Key Features:

• Compact design with a narrow width of just 1030 mm – ideal for confined spaces
• Rubber tracks for enhanced traction and reduced ground disturbance
• Strong hydraulic system with 17 Mpa pressure for reliable lifting and loading performance
• Efficient cycle times with quick raise, dump, and lower functions
• Maximum operator comfort with low noise levels (≤95 dB)

Specifications:

• Max Working Height: 2474 mm (97.4 in)
• Max Pin Height: 1977 mm (77.83 in)
• Max Dumping Height: 1275 mm (50.2 in)
• Max Dumping Distance: 175 mm (6.89 in)
• Max Dumping Angle: 70°
• Rollback on Ground: 25°
• Departure Angle: 23°
• Total Height: 1300 mm (51.18 in)
• Ground Clearance: 120 mm (4.72 in)
• Wheelbase: 890 mm (35.04 in)
• Overall Length (with bucket): 2319 mm (91.3 in)
• Overall Length (without bucket): 1767 mm (69.57 in)
• Folded Length (without bucket): 1633 mm (64.29 in)
• Total Width: 1030 mm (40.55 in)
• Bucket Width: 1070 mm (42.13 in)
• Turning Radius: 1440 mm (56.69 in)

• Rated Power: 18.2 kW (23 HP) Briggs N Stratton Engine @ 3600 rpm
• Hydraulic Pressure: 17 Mpa
• Working Time: Raise – 4s / Dump – 1.3s / Lower – 3.2s
• Loading Capacity: 390 kg (859.8 lb)
• Max Lifting Force: 450 kg (992 lb)
• Bucket Capacity: 0.13 m³ (4.59 ft³)
• Travel Speed: 0–4.5 km/h (2.8 mph)
• Operating Weight: 960 kg (2116 lb)
• Noise Level: ≤95 dB
