3.5T 4WD Rough Terrain Forklift
$35,950
Four Wheel Drive
Lift height available from: 3m- 6m
Hydraulic Fork Positioner
Lift height available from: 3m- 6m
Hydraulic Fork Positioner
The CDY-35 3.5T 4WD Rough Terrain Forklift is built for demanding outdoor worksites, combining serious lifting capacity with excellent traction and manoeuvrability. Featuring 3,500kg lift capacity, four-wheel drive, 320mm ground clearance, Side Shift and a Hydraulic Fork Positioner, it is ideal for construction sites, farms, timber yards, civil works and industrial applications. Powered by a 36.8kW Quanchai turbo diesel engine with a hydraulic torque-converter transmission, the CDY-35 delivers dependable performance across uneven and unsealed terrain.
3.5T 4WD Rough Terrain Forklift
3.5-Tonne Capacity. 4WD. Side Shift. Hydraulic Fork Positioner.
When the job moves beyond smooth concrete, you need a forklift built for real outdoor conditions.
The 3.5T 4WD Rough Terrain Forklift combines serious lifting capacity with four-wheel drive, high ground clearance, heavy-duty off-road tyres and a compact rear-steer design.
This latest configuration is fitted with Side Shift and a Hydraulic Fork Positioner, allowing the operator to accurately position both the carriage and fork spacing hydraulically from the driver’s seat.
It is a practical, heavy-duty material handling solution for construction sites, farms, rural properties, timber yards, building supply yards, civil works, machinery yards and outdoor industrial applications.
3,500 kg Rated Capacity
The Forklift has a rated lifting capacity of 3,500 kg at a 600 mm load centre, providing the capacity required for pallets, building materials, machinery, bulk products and general industrial loads.
Available mast configurations provide lifting heights from 3,000 mm through to 6,000 mm, depending on the specification selected.
A heavy-duty 160 mm reinforced mast section provides additional strength for demanding applications.
Genuine 4WD Rough Terrain Capability
The Forklift is designed specifically for work where conventional warehouse forklifts can struggle.
Its four-wheel-drive system, 320 mm ground clearance and large 20.5/70-16 semi-solid tyres provide the traction and clearance needed to operate across unsealed yards, gravel, compacted soil and uneven work sites.
Manufacturer specifications include:
- 4-wheel drive
- 320 mm ground clearance
- Maximum climbing angle: ≤38°
- Maximum traction force: 30.0 kN
- Maximum travel speed: 35 km/h
Whether you're loading materials on a building site, handling equipment around a farm or working across a large outdoor yard, the CPCDY-35 is designed to keep working when the surface is less than perfect.
Side Shift as Standard
Side Shift allows the entire fork carriage to move left or right hydraulically.
Instead of repeatedly repositioning the complete forklift to line up with a pallet or load, the operator can make fine lateral adjustments from the driver's seat.
That means:
- Faster pallet alignment
- More accurate load placement
- Less manoeuvring in tight spaces
- Reduced operator effort
- Improved productivity during repetitive loading work
Hydraulic Fork Positioner
The Forklift is also fitted with a Hydraulic Fork Positioner.
This allows the operator to hydraulically adjust the spacing between the forks from the driving position.
There is no need to continually climb out of the forklift and manually reposition the forks when changing between different pallet or load widths.
Combined with Side Shift, the hydraulic fork positioner provides substantially greater flexibility when handling different loads throughout the working day.
Quanchai Turbo Diesel Power
Power comes from a Quanchai 495 turbocharged diesel engine with high-pressure common-rail fuel delivery.
Rated output is 36.8 kW, providing the torque required for heavy lifting and rough-terrain operation.
The engine is matched to a 280 high/low-range hydraulic torque-converter transmission, designed to provide smooth power delivery and straightforward operation in changing site conditions.
Compact Rear-Steer Design
Despite its heavy-duty construction and approximately 5.6 to 5.9 tonne operating weight, the Forklift remains highly manoeuvrable.
A 2,500 mm minimum turning radius, 1,697 mm wheelbase and rear-axle steering make it particularly useful in confined yards and work areas where a larger machine can become difficult to manoeuvre.
Overall machine dimensions are approximately:
2980 mm long × 1550 mm wide × 2250 mm high
Heavy-Duty Mast and Fork Assembly
The Forklift incorporates a reinforced mast structure designed for demanding commercial use.
Standard specification includes:
- 160 mm reinforced mast section
- 10° forward mast tilt
- 20° rear mast tilt
- 1,220 mm forks
- Side Shift
- Hydraulic Fork Positioner
Alternative fork lengths and mast configurations can be specified depending on application.
Key Specifications
Model: CDY-35 Integrated Luxury Model – Simple Canopy
Machine Type: 4WD Rough Terrain Forklift
Rated Capacity: 3,500 kg
Load Centre: 600 mm
Lift Height: 3,000–6,000 mm, depending on mast configuration
Drive: Four-wheel drive
Engine: Quanchai 495 turbo diesel
Engine Output: 36.8 kW
Fuel System: High-pressure common rail
Transmission: 280 high/low-range hydraulic torque converter
Steering: Rear-axle steering
Maximum Travel Speed: 35 km/h
Maximum Climbing Angle: ≤38°
Ground Clearance: 320 mm
Minimum Turning Radius: 2,500 mm
Maximum Traction Force: 30.0 kN
Mast Tilt: 10° forward / 20° rear
Mast Section: 160 mm reinforced type
Fork Length: 1,220 mm
Side Shift: Included
Hydraulic Fork Positioner: Included
Tyres: Chaoyang 20.5/70-16 semi-solid
Wheelbase: 1,697 mm
Operating Weight: Approx. 5,600–5,900 kg
Overall Dimensions: 2980 × 1550 × 2250 mm
Ideal For
Construction Sites
Farms and Agricultural Properties
Civil Contractors
Building Supply Yards
Timber and Fencing Yards
Landscape Supply Businesses
Machinery and Equipment Yards
Outdoor Warehousing
Rural Businesses
Hire and Rental Fleets
Industrial Sites
General Rough-Terrain Material Handling
Built for Work Beyond the Warehouse
A standard forklift is at its best on smooth, level concrete.
The CDY-35 is built for businesses that don't always have that luxury.
With 3.5-tonne lifting capacity, four-wheel drive, 320 mm ground clearance, Side Shift and hydraulic fork positioning, it delivers the capability needed to move heavy loads efficiently across demanding outdoor work sites.
Serious lifting capacity for serious outdoor work.
